Frame
500 Series OCLV Carbon, IsoSpeed, internal storage, tapered head tube, internal cable routing, 3S chain keeper, mudguard mounts, flat mount disc, 142x12 mm thru axle
-
Fork
Domane SL carbon, tapered carbon steerer, internal brake routing, mudguard mounts, flat-mount disc, 12x100 mm thru axle
-
Weight
56 - 8.89 kg / 19.6 lbs (with TLR sealant, no tubes)
-
Weight limit
This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
-
Battery
Shimano BT-DN300
-
Charger
Charging cable included
-
Shifter
Shimano 105 R7170, 12-speed
-
Front derailleur
Shimano 105 R7150 Di2, braze-on, down swing
-
Rear derailleur
Shimano 105 R7150 Di2, 36T max cog
-
Crank
Size: 44, 47, 50 Shimano 105 R7100, 50/34, 165 mm length; Size: 56, 52, 54 Shimano 105 R7100, 50/34, 170 mm length; Size: 58, 60, 62 Shimano 105 R7100, 50/34, 172.5 mm length
-
Bottom bracket
Praxis, T47 threaded, internal bearing
-
Cassette
Shimano 105 7101, 11-34, 12-speed
-
Chain
Shimano SLX M7100, 12-speed
-
Max. chainring size
1x: 48T, 2x: 52/36
-
Wheel front
Bontrager Aeolus Elite 35, OCLV Carbon, Tubeless Ready, 35 mm rim depth, 100x12 mm thru axle
-
Wheel rear
Bontrager Aeolus Elite 35, OCLV Carbon, Tubeless Ready, 35 mm rim depth, Shimano 11-speed freehub, 142x12 mm thru axle
-
Skewer front
Bontrager Switch thru-axle
-
Skewer rear
Bontrager Switch thru-axle, removable lever
-
Rim strip
Bontrager TLR
-
Max tyre size
38 mm without mudguards, 35 mm with mudguards (as measured, see manual for details)
-
Saddle
Verse Short Comp, steel rails, 145 mm width
-
Seatpost
Size: 44, 56, 47, 50, 52, 54 KVF aero carbon seat post, 20 mm offset, 280 mm length; Size: 58, 60, 62 KVF aero carbon seat post, 20 mm offset, 320 mm length
-
Handlebar
Size: 44, 47 Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 36 cm control width, 40 cm drop width; Size: 50, 52 Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 38 cm control width, 42 cm drop width; Size: 56, 58, 54 Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 40 cm control width, 44 cm drop width; Size: 60, 62 Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 42 cm control width, 46 cm drop width
-
Handlebar tape
Trek EcoTack
-
Stem
Size: 44 Trek RCS Pro, -7-degree, 60 mm length; Size: 47 Trek RCS Pro, -7-degree, 70 mm length; Size: 50 Trek RCS Pro, -7-degree, 80 mm length; Size: 52, 54 Trek RCS Pro, -7-degree, 90 mm length; Size: 56, 58 Trek RCS Pro, -7-degree, 100 mm length; Size: 60, 62 Trek RCS Pro, -7-degree, 110 mm length
-
Brake rotor
Size: 44, 56, 47, 58, 60, 50, 62, 52, 54 Shimano CL700, CentreLock, 160 mm; Size: 44, 56, 47, 58, 60, 50, 62, 52, 54 Shimano RT70, CentreLock, 160 mm
-
Rotor size
Max brake rotor sizes: 160 mm front and rear
